Model: 8 Head Multi-Filling Machine
Production Capacity
- Carbonated: 7000 to 8000 units per day
- Non-carbonated: 6000 to 7000 units per day
Nozzles
- 5 Soda filling nozzles (Carbonated)
- 3 Syrup filling nozzles (Non-Carbonated)
8 Head Multi-Filling Soda Machine
|
8 Head Multi-Filling Soda Machine
Product Description
Description
- Fully automatic advanced filling machine
- Easy to operate and work with
- Full Stainless Steel Body (304)
- 1 Main part measurement - Filling part
- 2 Part measurement - Carbonated and cooling storage part
- 3 Ton Online chiller Compressor: 1.5 Ton | 1.5 Ton
- 2 in 1 function (Carbonated & Non-carbonated production)
- 4 Part 1 Capping machine with trolley (Manual)
- Operating at 1-degree temperature
- Three-phase machine/ Single-phase machine
- 8 Filling heads
- 5 Half HP Motors
- 5 Pumps (Made in Italy)
- 5 Carbonator tanks
- 5 Water coils
- 5 Soda coils
- 5 Heavy-duty regulators
- Automatic operating system with perfect accuracy
- Power: 220 Volts, 50 Hz (5 KW)
- Chiller tank capacity: 300 Ltr and 180 Ltr
Dimensions
- Main Dimensions (L x D x H): 74" x 22" x 72"
- Chiller tank Dimensions (L x D x H): 68" x 28" x 48"
Weight
- Net weight Part 1: 270 kg (approx.)
- Net weight Part 2: 230 kg (approx.)
- Net weight Part 3: 200 kg (approx.)
- Gross weight Part 2: 500 kg (approx.)
Main Complementary Items
- Manual Date Coding Machine
- Manual Capping Machine
- Hot Gun for Outer Shrink Packing
- Spare parts and Tool Kit
- Machine Graphic Design
- Cap Stand
- RO Plant
- 100% Stainless Steel Washer Table
- First-time Free Flavor
- CO2 Cylinder
- First-time Bottles & Caps
- Installation and Training
Overview
The 8 Head Multi-Filling Machine is a highly efficient, fully automatic filling solution designed for both carbonated and non-carbonated production. With a stainless steel body, high-capacity production, and advanced cooling and carbonation systems, it is perfect for businesses seeking a versatile and reliable soda bottling solution. This machine is equipped with multiple filling heads, advanced pumps, and a chiller system, ensuring high-speed operation and consistent product quality.
