Automatic Filling Soda Machine (Fully Automatic System)

Model: Automatic Filling Soda Machine (Fully Automatic System)

Production Capacity

  • 12,000 to 13,000 bottles per day
  • Only one labour required to operate the machine

Nozzles

  • 3 Soda Filling System
  •  3 Syrup Filling System
  •  1 CO2 Filling System
  • Description
  • Dim and Weight
  • Complementary Items

Product Description

Description

  • Easy to operate and work with
  •  Perfect accuracy of filling
  •  Sensor-based system for improved precision
  •  Air conveyor bottling system for efficient movement
  •  Star plate with 9-head bottle capacity for capping
  •  Out Soda Stainless Steel Conveyor
  •  Produces 100% strong soda with the best quality
  •  304 Stainless Steel Body for durability and quality
  •  Chilling and storage body to keep production stable
  •  Chiller Tank made from 304 Stainless Steel
  •  4 Ton Chiller Compressor (Advanced power-saving, double chilling: 2 Ton + 2 Ton)
  •  Chiller tank capacity for effective cooling
  •  1 Heavy Duty Regulator
  •  Half HP Motor x 3 pieces
  •  3 Heavy Carbonator Systems for efficient carbonation
  •  1 Syrup Output Pump (Made in Italy)
  •  1 Syrup Imported Pump (Non-earth pump)
  •  2 Head Washing Table for cleaning bottles before filling
  •  250 Litre / Hour RO Plant for purified water
  •  300 Litre Sugar Melting Tank for syrup preparation
  •  500 Litre Syrup Mixing Tank for consistent blending
  •  Date Coding Machine for labeling and tracking
  •  2-in-1 function for both carbonated and non-carbonated production
  •  Digital controlling operating system, supports various capacities (200ml, 300ml, 400ml, 2.00ltr, 2.25ltr, etc.)
  •  Three-phase connection required
  •  Power consumption: 8 KW

Dimensions

  • Machine (L x D x H): 71" x 77" x 85"
  • Chiller Tank (L x D x H): 68" x 33" x 70"



Main Complementary Items

  • Manual Date Coding Machine
  •  Manual Capping Machine
  •  Hot Gun for Outer Shrink Packing
  •  Spare parts and Tool Kit
  •  Machine Graphic Design
  •  Cap Stand
  •  RO Plant
  •  100% Stainless Steel Washer Table
  •  First-time Free Flavor
  •  CO2 Cylinder
  •  First-time Bottles & Caps
  •  Installation and Training

Overview

The Automatic Filling Soda Machine offers an advanced, fully automated solution for bottling both carbonated and non-carbonated beverages. Featuring a sensor-based filling system and air conveyor system, this machine ensures accuracy and efficiency while requiring minimal labor. With high-capacity production, multi-stage chilling, and carbonation systems, it can handle a variety of beverage types with exceptional quality and consistency. The integrated syrup and sugar melting tanks, RO plant, and chiller compressor system make it an ideal choice for businesses seeking high-performance bottling for large-scale production.
